Place of Origin: | China |
---|---|
Brand Name: | GNGTHISM |
Certification: | CE/ISO9001 |
Model Number: | GNNBG |
Minimum Order Quantity: | Negotiation |
Price: | Negotiation |
Packaging Details: | standard export package |
Delivery Time: | 3~15 days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 30 sets per month |
Material: | SS304/SS316L | Usage: | Nano Bubble Generator |
---|---|---|---|
Gas-liquid Dissolving Rate: | 85-90% | Model: | GNNBG-12 |
Flow Rate: | 12 M3/h | Package: | Wooden Case |
High Light: | micro bubble machine,dissolved oxygen generator |
New design micro nano bubble generator with oxygen source ozone for aquaculture
This micro nano bubble generator is composed of motor, motor base, air-intake driving shaft, oil seal, mechanical water seal and impeller.
The impeller underwater is powered by a motor.Wastewater firstly enters into the aeration chamber, with the high-speed rotation of the impeller, a vacuum zone is formed underwater, which will absorb and dissolve the air above water level into water and generate millions of micro nano bubbles.
Technical Parameters
Model | GNNBG-01 | GNNBG-02 | GNNBG-05 | GNNBG-12 | GNNBG-30 |
Flow Rate | 1 | 2 | 5 | 12 | 30 |
(m3/h) | |||||
Power of Pump | 0.55 | 1.1 | 2.2 | 3 | 7 |
(KW) | |||||
Affected Water Area(m2/D) | 300-400 | 900-1200 | 1900-2600 | 4600-5300 | 12000-14000 |
Working Temps(℃) | 0-100 | 0-100 | 0-100 | 0-100 | 0-100 |
Bubble Diameter(nm/μm) | 200nm-50μm | 200nm-50μm | 200nm-50μm | 200nm-50μm | 200nm-50μm |
Gas-liquid Mixture Ratio | 1:6-1:9 | 1:6-1:9 | 1:6-1:9 | 1:6-1:9 | 1:6-1:9 |
Gas-liquid Dissolving Rate | 85-90% | 85-90% | 85-90% | 85-90% | 85-90% |
Application
The micro bubble generator’s ideal fields of application includes the treatment of oil-water emulsions, fat separations, phosphate precipitations and heavy metal precipitations as well as final sedimentation at bio-treatment plants. Multistage flotation plants are a solution to the treatment of special waste.
