| Place of Origin: | China |
|---|---|
| Brand Name: | GNGTHISM |
| Certification: | CE/ISO9001 |
| Minimum Order Quantity: | Negotiation |
| Price: | Negotiation |
| Packaging Details: | Wooden Box |
| Delivery Time: | 3~15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 30 sets per month |
| Material: | Stainless Steel | Application: | Pharmaceutical Factory |
|---|---|---|---|
| Color: | Blue | Warranty: | 1 Year |
| Package: | Wooden Box | Certification: | CE/ISO9001 Certificate |
| High Light: | centrifugal turbo air blower,suspension turbo air blower,steel high speed turbo blower |
||
Core Advantages of Air Turbo Blower
1. High efficiency and super energy saving: the air foil centrifugal blower adopts air foil bearing and high-speed permanent magnet motor direct drive structure, and the transmission efficiency reaches 100%; The impeller adopts hydrodynamic three-dimensional flow design to ensure the highest aerodynamic efficiency, which can save energy by 30% ~ 50% compared with the traditional Roots blower;
2. No oil, low energy consumption: the air foil blower adopts air foil bearing technology, and the whole system runs without friction, low energy consumption, no lubricating oil and no maintenance;
3. Low noise and small size: the noise only comes from the friction sound between the medium and the pipe wall when flowing, and the equipment itself basically does not produce noise, with an average noise of < 80 decibels; The volume is about 50% smaller than the roots blower of the same specification, and the installation is convenient and simple;
4. Variable frequency and wide range: the variable frequency range is 45~100% when the equipment is running, and the application range is wide;
5. Cloud service, easy operation: Cloud service tracks customer terminals, and is modular in design, making maintenance convenient and quick.
Product Parameters
Functional characteristics and cost comparison
1. Compact size
Our turbo blower is only one third the size of Roots blower
2. Simple maintenance
Maintenance can be completed only by regularly replacing the filter with a new one
Improve the quality of compressed air by using two filters (filter+filter cotton).
3. Use high-quality quality filter to reduce pressure loss
4. Low noise and vibration
Adopt air bearing direct connection technology, without mechanical wear, only 75~80db@1m low noise, without sound insulation device
5. The vibration of the centrifugal blower product which realizes continuous suction and discharge is ZERO level
6. Convenient remote control
Through various network facilities such as network, wireless network, mobile device and telephone network, real remote control can be realized anytime and anywhere
